चीन औद्योगिक धातु एल्यूमिनियम 1kw 2kw शीट धातु फाइबर लेजर काटने की मशीन

Configuration:

1. Adopt industrial heavy duty steel structure, plate steel joint welding with square pipe steel, under heat treatment, will not deform after long time using.

2. Configure with Japan THK linear rail for all axis, to ensure durable and high precision for long time processing.

3. एक्स, वाई अक्ष उच्च सटीकता पीसने वाले प्रकार गियर रैक, जापान शिम्पो रेड्यूसर, उच्च गति और परिशुद्धता के साथ कॉन्फ़िगर किया जा सकता है, जेड अक्ष उच्च सटीकता रोलिंग बॉल स्क्रू द्वारा प्रेषित कर रहे हैं।

4. Adopt France Schneider AC servo system for all axis, larger power, close-cycle control, high precision positioning, stronger torque force, dynamic corresponding time is shorter, and the overload resistance ability is strong.

5. Adopt industrial optical fiber cutting system, easy to install, maintenance and cam module based on autocad kernel development, built-in process, ensure high-quality cutting effect.

6. Adopt professional WSX, Raytools laser cutting head, imported optical lens, focus spot smaller, cutting lines more precise, higher efficiency and better processing quality can be ensured.

7. Dual air path control, equipped with Japan SMC intelligent gas unit, automatic pressure regulation, air exchange, pressure detection, more simple to use.

8. Fiber laser transmitting, flexible processing, realized high accuracy cutting on every point.

9. Compatible with multiple software, can design ant graphic and letters as you like, operating simple, flexible and easy.

विशेषताएं

1. Adopt heavy duty structure, CNC machinery center processing and forming, high strength and good stability;

2. More stronger cast iron stand to keep the machine working more stable;

3. Configure with high accuracy THK linear rail, high accuracy helical gear rack transmitting,more stability,higher precision;

4. Restart from power off, auto feeding, restoration, continue processing at break point. Support 9 coordinate setting, user friendly design;

5. Configured with SUDA 3 in 1 control system, quickcalculation, strong anti-interference ability;

6. Equipped with industrial camera,the probe is clear. High positioning precision;

7. Standard configured with 380V 5.5KW high speed water cooling spindle motor, high power high efficiency;

8. Independent control cabinet, stronger power and weak power separate, maintenance easily;

9. Be compatible with many CAD/CAM software like Type3/Artcam/Castmate/Probe/UG/Artgrave etc;

10. Standard with industrial matrix vacuum system;

11. Configure with manual oil lubrication system. Equipment maintenance is more convenient and quick.

Main Parts

Machine Structure

The machine structure adopts industrial heavy steel structure, under heat treatment, suffer lower temperature tempering and annealing, won't deform after long time use. the machine base is very stable when the processing.

Japan THK Linear Rail and Block

The machine adopts the best linear and block rail from Japan. We have the feedback from our client that its block even can use over 10 years and can't break.The usage lifespan and the product quality definitely can be ensured.

France Schneider Servo System

The fiber laser machine adopts the imported servo system from France including servo motor and servo driver, The Y axis two servo motor power are 2KW, The X axis servo power is 2KW power, The Z axis servo motor power is 0.4KW power.

CYPCUT Control System

The best control system in fiber laser machine industry,
It is suitably applied to high power fiber laser machine and can support the rotary device, exchange table and automatic focus cutting head.

S & A Chiller

Focus on the research and development of industrial cold machine, independent research and development of core parts strictly implement ISO production management system, With excellent quality and leading research retrength, S &A has become a leding enterprise in the domestic industrial refrigeration industry.

Raycus Laser Source

Fiber laser is compact in structure, stable in performance and widely used, Fiber laser has high photoelectric conversion efficiency, good beam quality and low maintenance cost,(The USA IPG Laser source is optional)

Japan Shimpo Servo Reducer

Our fiber laser machine adopts the Shimpo Servo Reducer from Japan with low noise when the machine is processing the metal materials,After many refinements,it has small size in installation but high precision function.

WSX Fiber Laser Cutting Head

Our fiber laser machine 1000 watt install the WSX NO:1 manual focus cutting head.

The machine also can optional the NC30 automatic focus cutting head, Fast perforation (especially the thick materials), The plate is not easy to heat, Does not affect the cutting head following.

Oil Lubrication System

This machine accessory is applied to lubricate the machine rail and block in order that it runs smoothly and fast, improving the working efficiency.

 Application&Sample

विवरण

• Application: LASER CUTTING, laser cutting
• Applicable Material: Metal, aluminum Cooper carbon stainless steel
• स्थितिः नई
• लेजर प्रकार: फाइबर लेजर
• Cutting Area: 1300*2500mm
• Cutting Speed: 20m/min
• Graphic Format Supported: AI, PLT, DXF, Dwg
• Cutting Thickness: depending on the materials
• सीएनसी या नहीं: हाँ
• कूलिंग मोड: वाटर कूलिंग
• Control Software: Schneider AC servo system
• उत्पत्ति का स्थान: अनहुई, चीन
• लेजर स्रोत ब्रांड: रेकस
• लेजर हेड ब्रांड: WSX
• सर्वो मोटर ब्रांड: श्नाइडर
• गाइडरेल ब्रांड: THK
• नियंत्रण प्रणाली ब्रांड: साइपकट
• Weight (KG): 2900 KG
• प्रमुख विक्रय बिंदु: उच्च सुरक्षा स्तर
• ऑप्टिकल लेंस ब्रांड: तरंग दैर्ध्य
• 1 साल की वॉरंटी
• Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Retail, Printing Shops, Construction works , Energy & Mining, Advertising Company
• मशीनरी परीक्षण रिपोर्ट: बशर्ते
• वीडियो आउटगोइंग-निरीक्षण: बशर्ते
• मुख्य घटकों की वारंटी: 1 वर्ष
• Core Components: Motor, Gear, Engine, PLC, laser power
• ऑपरेशन का तरीका: निरंतर तरंग
• विन्यास: 3-अक्ष
• उत्पाद संभाला: शीट धातु और ट्यूब
• फ़ीचर: वाटर-कूल्ड
• Product name: FC1325 FC1530
• Laser power: 1000W
• Laser source: Raycus (optional IPG)
• Servo motor: France Schneider
• Laser head: WSX /Raytools
• Positioning Accuracy: 0.05 Mm
• Linear rail: Japan THK
• Reducer: Japan Shimpo reducer
• कार्य क्षेत्र: 3000 * 1500 मिमी
